遥控、防盗报警用单端对声表面波谐振器
|
型号
|
标称频率
(MHz)
|
插入损耗
(dB)
|
质量因素
|
封装
|
|
卸载
|
50Ω
负载
|
|
p260
|
260.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p300
|
300.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p303.825
|
303.825
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p303.875
|
303.875
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p304.25
|
304.250
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p310
|
310.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p311.063
|
311.063
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p314.5
|
314.500
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p315
|
315.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p316.8
|
316.800
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p318
|
318.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p319.8
|
319.800
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p325
|
325.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p330
|
330.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p340
|
340.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p345
|
345.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p350
|
350.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p360
|
360.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p384
|
384.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p390
|
390.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p395
|
395.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p396
|
396.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p400
|
400.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p403
|
403.050
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p418
|
418.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p420
|
420.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p423.22
|
423.220
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p426
|
426.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p430.55
|
430.550
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p433.42
|
433.420
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p433.92
|
433.920
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p435.72
|
435.720
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p436.925
|
436.925
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p446
|
446.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p447.625
|
447.625
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p466
|
466.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p479.5
|
479.500
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p480
|
480.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p868.35
|
868.350
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p912
|
912.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p916.5
|
916.500
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
p980
|
980.000
|
≤2.0
|
≥12,000
|
≥2,000
|
TO-39,F11
|
|
1.
※The
other than above products in frequency range of
200 to 900 MHz are available
※The
frequency tolerances ± 50kHz,± 75kHz,± 100kHz,±
150kHz,± 200kHz,± 250kHz are available
|
〓遥控、报警用双端对声表面波谐振器
〖返回顶部〗
|
型号
|
标称频率
(MHz)
|
插入损耗
(dB)
|
质量因素
|
封装
|
|
卸载
|
50Ω
负载
|
|
p310
|
310.000
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p315
|
315.000
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p384.05
|
384.050
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p387
|
387.000
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p403.55
|
403.550
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p418
|
418.000
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p423
|
423.220
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p433.92
|
433.920
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p455.86
|
455.860
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
p82425
|
824.250
|
≤7.5
|
≥13,000
|
≥6,500
|
TO-39,F11
|
|
※The
other than above products in frequency range of
200 to 900 MHz are available
※The
frequency tolerances ± 50kHz,± 75kHz,± 100kHz,±
150kHz,± 200kHz,± 250kHz are available
|
|
〓窄带声表面波滤波器
〖返回顶部〗
|
型号
|
标称频率(MHz)
|
频率偏差
|
3dB带宽
|
插入损耗
|
封装
|
|
P315A
|
315.000
|
±
100KHz
|
500KHz
|
≤3
dB
|
TO-39,F11
|
|
P418A
|
418.000
|
600KHz
|
≤3.5
dB
|
|
P433A
|
433.920
|
700KHz
|
≤1.7
dB
|
|
P868
|
868.350
|
900KHz
|
≤3.5
dB
|
|
P916
|
916.500
|
〓通讯系统用声表面波滤波器
〖返回顶部〗
|
型号
|
P110A
|
P110N
|
|
典型值
|
极限值
|
|
标称频率(Fc)
|
110
MHz
|
FC
± 150KHz
|
110.592
MHz
|
|
插入损耗(ref.)
|
6.0
dB max.
|
7.0
dB max.
|
4.5
dB max.
|
|
3dB带宽
|
1.5
kHz
|
|
±
576 kHz
|
|
40dB带宽
|
|
7.0MHz
max.
|
|
|
相对哀耗
Fc+475KHz
Fc-425KHz
Fc+1375KHz
Fc-1395KHz
Fc+1.5M to Fc+10MHz
Fc-1.355M to Fc-10MHz
|
45 dB min.
45 dB min.
|
3 dB min.
3 dB min.
30 dB min.
30 dB min.
|
Fc-3X1.728MHz
Fc-2X1.728MHz
Fc
± 1.150MHz
Fc
± 1.728MHz
Fc
+ 2X1.7280MHz
Fc
+ 3X1.7280MHz
|
50 dB min.
45 dB min.
10 dB min.
30 dB min.
40 dB min.
40 dB min.
|
|
群延时波动
|
150
uS
|
300
uS max.
|
Fc
± 576MHz
|
0.7
uS max.
|
|
输入/输出阻抗
|
75
Ω ∥-5.6pF
|
|
300
Ω ∥1.2uH
|
|
|
|
〓传呼机用声表面波滤波器
〖返回顶部〗
|
型号
|
P139/147/
155/163/171
|
|
标称频率(Fo)
|
110.592
MHz
|
|
插入损耗
Fc-100MHz to Fc-46.8MHz
Fc-46.8MHz to Fc-38.8MHz
Fc±4MHz
Fc+38.8MHz to 2.5XFo
|
50 dB max.
50 dB min.
6.5 dB max.
42 dB min.
|
|
输入/输出阻抗
|
210
Ω ∥-13.3pF
|
|
|
型号
|
P280/281
|
|
标称频率(Fo)
|
280.0/281.0
MHz
|
|
插入损耗
Fc-100MHz to Fc-37.5MHz
Fc±5MHz
Fc+37.5MHz to100MHz
波纹(±5MHz) |
48 dB min.
4.5 dB max.
40 dB min.
2.0 dB max.
|
|
输入/输出阻抗
|
230
Ω ∥-
0.2pF
|
|
|
|
|
|
|
BXF155
幅频特性
|
BXF325
幅频特性
|
F11外型尺寸
|
|
|
〓通讯对讲机用声表面波滤波器
〖返回顶部〗
|
型号
|
P465
|
P446
|
P410
|
|
标称频率(Fo)
|
465
MHz
|
446
MHz
|
410
MHz
|
|
3dB
带宽
|
F0
± 2MHz
|
|
插入损耗(ref.)
相对哀耗
Fc-100MHz
to Fc-40.8MHz
Fc±3.0MHz
Fc+40.8MHz
to Fc+100MHz
|
55 dB min.
4.5 dB max.
55 dB min.
|
|
输入/输出阻抗
|
50
Ω/150Ω∥
0pF
|
※以上400MHz～600MHz标称频率范围内可提供！
|
〓卫星接收机用声表面波滤波器
〖返回顶部〗
|
标称型号
|
P480-1
|
P480-2
|
P480-3
|
P480-5
|
P480-6
|
P480-7
|
P480-8
|
|
频率(MHz)
|
480.0
MHz
|
479.5
MHz
|
480.0
MHz
|
|
插入损耗(dB)
|
19.5.
|
20.0
|
21.0
|
21.8
/ 22.0
|
20.6
/ 21.0
|
19.6
/ 25.0
|
|
3dB
带宽(MHz)
|
17.6
|
26.6
|
36.2
|
15.0/27.0
|
18.0/27.0
|
27.0/36.0
|
26.8/53.6
|
|
高端阻带抑制(dB)
|
45
|
43
|
42
|
44.5/41.6
|
42.0/43.0
|
39.0/36.0
|
37.0/38.0
|
|
低端阻带抑制(dB)
|
50
|
46
|
41
|
45.5/41.8
|
48.0/43.0
|
39.0/39.0
|
48.0/43.0
|
|
群延时波动(nS)
|
11.5
|
8.5
|
3.0
|
9.6/8.0
|
11/11
|
10/12
|
14/12
|
|
输入/输出阻抗(Ω/pF)
|
70/3.7
250/2.5
|
60/4.8
260/13.1
|
180/3.8
140/3.3
|
170/3.6
130/3.3
|
200/3.6
240/3.9
|
90/5.0
510/5.0
|
〓卫星接收机用38M中频残留边带滤波器
〖返回顶部〗
|
型号
|
图像载频
(MHz)
|
通带宽度
(MHz)
|
带内波动
(dB)
|
插入损耗
(dB)
|
带外抑制
(dB)
|
群时延波动
(nS)
|
外形
|
|
P38-1
|
38
|
31.3～38.75
|
≤±0.5
|
≤22
|
≥45
|
±50
|
SC-8
|
|
|
※工程机用于中放前作邻频抑制用，避免邻频串扰(在30MHz和39.5MHz处有足够的抑制、矩形系数好，插损小)
|
〓光纤通讯、光端机用声表面波滤波器
〖返回顶部〗
|
标称频率
|
3dB带宽
|
插入损耗(ref.)
|
频率偏差
|
|
16.896
MHz
|
150
kHz
|
≤15
dB max.
|
±
50 kHz
|
|
20.48
MHz
|
|
21.24
MHz
|
|
28.80
MHz
|
|
32.768
MHz
|
|
33.792
MHz
|
|
34.368
MHz
|
|
40.96
MHz
|
|
42.24
MHz
|
|
42.96
MHz
|
〓数传电台、车载电话、无线数传、四表查送用声表面波滤波器
〖返回顶部〗
|
标称频率
|
3dB带宽
|
插入损耗(ref.)
|
输入/输出阻抗
|
|
230
MHz
|
3
MHz
|
<
5 dB max.
|
50
Ω
|
|
230
MHz
|
13
MHz
|
<
7 dB max.
|
|
460
MHz
|
20
MHz
|
<
5 dB max.
|
|
|
|
|
